Torq/Gard TG200 Taper Grip Clutch
Torq/Gard TG200 Taper Grip Clutch
Regular price
$2,715.00 USD
Regular price
Sale price
$2,715.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The Taper Grip Bushing (TGBU) is a tapered bushing that fits in the finished tapered bore, creating a final bore size of 1", 1.125", 1.25", or 1.75" based on the model. This enables a more adaptable shaft-mounting solution. The bore presses around the shaft as the bushing is tightened and expands inward.
The Torq/Gard TG200-TGBU is a torque-limiting power transmission overload clutch. The modular design accommodates direct drive, chain drive or other power transmission options and the universal mounting eliminates the need for special bore requirements.
Max Bore Size: 1, 1.125, 1.25, or 1.75 inches
Trip Torque Range: 600 - 2000 in-lbs
Max Power: 21.5 hp
Max Speed: 680 rpm
Weight: 12 lbs
Inertia: 46 lb-in2
The Torq/Gard TG200-TGBU is a torque-limiting power transmission overload clutch. The modular design accommodates direct drive, chain drive or other power transmission options and the universal mounting eliminates the need for special bore requirements.
Max Bore Size: 1, 1.125, 1.25, or 1.75 inches
Trip Torque Range: 600 - 2000 in-lbs
Max Power: 21.5 hp
Max Speed: 680 rpm
Weight: 12 lbs
Inertia: 46 lb-in2
Shipping
Shipping
Our Torq/Gard products are shipped from:
47517 Seabridge Drive
Fremont, CA 94538
US
We primarily use UPS.
Clutch Manual
Clutch Manual
Each Torq/Gard Clutch comes with a Manual. Manuals can also be viewed or downloaded here.
Returns
Returns
Please contact us for returns and cancellations. Each case will be reviewed and decided on a case-by-case basis. Product packaging must be unopened and in like new condition when received upon return. We want to help you and treat you fairly. We must be NOTIFIED within 2 weeks of placing the order, unless otherwise stated. Customer covers return shipping charges. There is a 20% restocking fee.
